Youritech OEM 10.1 Inch Free Angle 800x1280 Resolution with MIPI 40 Pins LCD Display PCAP Touch Panel For Industrial

Part No.:ET101WX03-T
Size:10.1″ inch
Resolution:800x1280
Panel Interface:MIPI 40 Pins
Display mode:Transmissive
Outline Dimension:159(W)x244.6(H)mm
Active Area:135.36(W)x218.57(H)mm(A.A)
Viewing Angle L/R/U/D:85/85/85/85
Brightness（cd/m2）:300(Typ.)
Operation / Storage Temp:-20~70°C / -30~80°C
Touch:no

Products Description

ET101WX03-T-10.1inch-TFT-800x1280-MIPI-IPS-2

Product size	10.1 inch	Type	a-Si TFT-LCD
Pixel Format	800×1280	Configuration	RGB Vertical Stripe
Active Area	135.36 (W) × 218.57 (H) mm (A.A)	Outline Dim.	159 (W) × 244.6 (H) mm
Luminance	300 (Typ.)	Contrast Ratio	1000:1 (Typ.)
View Direction	Symmetry	Polarizer	Transmissive
Viewing Angle	85/85/85/85 (L/R/U/D)	Operating Mode	-
Support Color	16.7M	Light Source	WLED
Aspect Ratio	10:16 (W:H)	Designed For	Industrial, Pad & Tablet
Form Factor	Flat Rectangle	Touch Panel	PCAP
Max. Depth	4.85 mm
Interface Type	MIPI 40 Pins
LC Family	IPS Family
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C

ET101WX03-T_01 ET101WX03-T_02 ET101WX03-T_03
