SY103WAM01 1 inch 2560x2560 Si-OLED Panel Sunlight Readable MIPI Interface Amoled With Drive Board For HMD AR VR

SY103WAM01 Overview
SY103WAM01 is a 1.0 inch diagonal Si-OLED display screen product, it self emiting, without touch screen. SY103WAM01 supports display 2560(RGB)×2560 with aspect ratio of 1:1 (W:H), whose pixels are arranged in RGB π type, it's pixel density is 3527 PPI. As for mechanical detail, it features active area of 18.432(W)×18.432(H) mm, outline size of 21.09(W)×22.77(H)×1.58(D) mm. SY103WAM01 can provides 1800 cd/m² display brightness 500000:1 transimissive contrast ratio, 30/30/30/30 (L/R/U/D) viewing angle.

Screen Size:1 inch
Resolution:2560x2560
Brand:SeeYA
High Resolution OLED Panel
Refresh Rate:90Hz

Feature
-High contrast
-Wide color gamut
-Quick response
-Sunlight Readable
-Brightness:1800 cd/m² (Typ.)
-Operating Temp. :-20 ~ 70 °C
-Storage Temp. :-40 ~ 80 °C

More SKU To Choose
-ET010SQH11 dual display with board 1800nits 1.03inch Tyep-C
-ET010SQH12 (one dispaly with board) 1800nits 1.03inch Tyep-c
-ET010SQH11 1800nits + HDMI board
-Type-C board (2 connectors)
-SY103WAM01 (2560x2560) 1.03inch 1800nits

Application
Head-mounted Displays, Viewfinders, Small Display,AR VR etc.

As one of the Pioneers within microdisplays products, Youritech have pushed energy efficiency to the edge, delivering high-performance Near-Eye Displays (NED) for a wide range of products, that include video glasses, head-mounted sports devices, camera viewfinders, medical applications, and many other professional devices worldwide.
