SeeYA SY083WAM01 0.83 Inch 2560x1440 OLED Display MIPI Interface Ultra High Brightness Amoled For HMD AR VR

Overview
SY083WAM01 is a 0.83 inch diagonal Si-OLED display screen product, it self emiting.SY083WAM01 supports display 2560(RGB)×1440 (Quad-HD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB π type, it's pixel density is 3527 PPI. As for mechanical detail, it features active area of 18.432(W)×10.368(H) mm, outline size of 21.09(W)×22.77(H)×1.58(D) mm. SY083WAM01 can provides 1800 cd/m² display brightness 500000:1 transimissive contrast ratio, best view direction on Symmetry , and response time of 1 (Max.)(G to G) ms.
Screen Size:0.83 inch
Resolution:2560x1440
Brand: SeeYA
High Resolution OLED Panel
Refresh Rate:90Hz

Feature
-High contrast
-Wide color gamut
-Quick response
-Thin and light
-Ultar high brightness

More SKU To Choose
-SY083WAM01 2560x1440 0.83inch micro oled
-ET010SQH11 (dual dispaly with board) 1800nits 0.83inch Tyep-c
-ET010SQH12 (one dispaly with board) 1800nits 0.93inch Tyep-c
-ET010SQH11 (dual dispaly with board) 1800nits 0.83inch HDMI
-Type-C board (2 connectors)

Application
Head-mounted Displays, Viewfinders, Small Display,AR VR etc.

As one of the Pioneers within microdisplays products, Youritech have pushed energy efficiency to the edge, delivering high-performance Near-Eye Displays (NED) for a wide range of products, that include video glasses, head-mounted sports devices, camera viewfinders, medical applications, and many other professional devices worldwide.
