| Product size | 7.9-inch | Type | Oxide TFT-LCD , LCM | |
| Pixel Format | 1536(RGB)×2048 [QXGA] 325PPI | Configuration | RGB Vertical Stripe | |
| Active Area | 119.808(H)×159.744(V) mm | Outline Dim. | 125.55(H)×171.3(V) ×3.15(D) mm | |
| Luminance | 460 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (TM) | |
| View Direction | Symmetry | Response Time | 35 (Typ.)(Tr+Td) | |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Operating Mode | IPS, Normally Black, Transmissive | |
| Support Color | 16.7M 70% NTSC | Light Source | WLED [6S4P] , W/O Driver | |
| Weight | 65.0g (Typ.) | Designed For | Pad & Tablet | |
| Frequency | 60Hz | Touch Panel | Without | |
| Interface Type | MIPI (2 ch, 4 data lanes) , 50 pins Connector | |||
| Power Supply | 1.8/5.6/-5.6V (Typ.)(IOVCC/VSP/VSN) | |||
| Environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C | |||
