| LCD SPECIFICATION | ||||
| Panel Size | 18.5" | Panel Type | a-Si TFT-LCD, LCM | |
| Pixel Number | 1920(RGB)×1080, FHD, 119PPI | Configuration | RGB Vertical Stripe | |
| Active Area(mm) | 408.96(W)×230.04(H) mm | Outline(mm) | 430.4(W)×254.6(H) ×14(D) mm | |
| Bezel Area(mm) | 413.4(W)×234(H) mm | Treatment | Antiglare, Hard coating (3H) | |
| Luminance | 400 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (TM) | |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) | Display Mode | SFT, Normally Black, Transmissive | |
| View Direction | Symmetry | Response Time | 25 (Typ.)(Tr+Td) | |
| Support Color | 16.7M 72% NTSC | Backlight | WLED , 50K hours , With LED Driver | |
| Weight | 1.55Kgs (Typ.) | Used for | Industrial | |
| Frame Rate | 60Hz | Touchscreen | Without | |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | |||
| Input Voltage | 5.0V (Typ.) | |||
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C | |||
