LS315M7JX01 Sharp 32 Inch TFT LCD Display 1920x1080 Reflective Sunlight Readable eDP LCD Module

Part No.:LS315M7JX01
Size:32″ inch
Resolution:1920x1080
Panel Interface:eDP (2 Lanes),eDP1.3
Display mode:Transflective
Outline Dimension:734x420mm
Active Area:696.96x392.04mm
Viewing Angle L/R/U/D:60/60/60/60 (Typ.)
Brightness（cd/m2）:28cd/m²(Typ.)
Operation / Storage Temp:-20~70°C / -20~70°C
Touch:no

LS315M7JX01 Overview

LS315M7JX01 supports display 1920(RGB)×1080 (FHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. It features active area of 696.96(W)×392.04(H) mm, outline size of 734(W)×420(H)×18.5(D) mm, viewing area size of 699(W)×394(H) mm, with surface treament of Hard coating (3H), net weight of 5.50Kgs (Typ.). As a Normally Black, Reflective LCM product, LS315M7JX01 can provides 27 cd/m² display brightness, 17:1 (Typ.) reflective contrast ratio, 60/60/60/60 (Typ.)(CR≥2) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 20 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 15% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, external backlight driver is additionally needed. LS315M7JX01 utilizes eDP (2 Lanes) as it's signal inputting systerm, which connected by 40 pins Connector with power supply voltage of 12V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
