LS050K7SX03 Sharp 5 Inch Sunlight Readable LCD 720x1280 Transflective LCD Display For Handheld PDA

LS050K7SX03 Overview

LS050K7SX03 is a 5.0 inch diagonal Oxide TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, without touch screen.LS050K7SX03 supports display 720(RGB)×1280 (WXGA) with aspect ratio of 9:16 (W:H), whose pixels are arranged in RGB Vertical Stripe, it's pixel density is 294 PPI. As for mechanical detail, it features active area of 62.1(W)×110.4(H) mm, outline size of 67(W)×120.57(H)×2.31(D) mm, with surface treament of Hard coating (2H), net weight of 32.0g (Typ.). As a New Mode2, Normally Black, Transflective LCM product, LS050K7SX03 can provides 150 cd/m² display brightness, 30:1 (Typ.) reflective contrast ratio, 60/60/60/60 (Typ.)(CR≥2) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 17/5 (Typ.)(Tr/Td) ms., also with performance of color gamut 15% (NTSC).

LS050K7SX03 Feature

-Portrait Type
-Transflective
-WLED Backlight
-Sunlight Readable

Screen Size:5 inch
Resolution:720x1280
Brand:Sharp
LS050K7SX03 Sharp 5 Inch 720x1280 Sunlight Readable LCD Display.

LS050K7SX03 Application

For Handheld&PDA,Industrial LCD.

To operate in low-light conditions, RLCDs need to be paired with an efficient front light solution such as the Youritech Front Light Panel.With improved optical coupling, collimation, and attenuation, our front light solution efficiently delivers more light exactly where you need it, and efficient LEDs can be used without experiencing typical issues with diffusion and material losses. Plus, as few as one low-power LED can be used in a front light instead of the five or more LEDs needed for alternative display light guides, making our solution the most efficient front light option available today.

It means your devices can stop relying on power-hungry backlights. By reinventing light guide and front light technology, we makes it possible to fully embrace the inherent power-saving features of RLCDs – from the brightest outdoor to the darkest indoor lighting environments.
