LS011B7DH03 Sharp 1.1 inch Sunlight Readable LCD 160x68 SPI 10Pins Reflective LCD For Wearable

LS011B7DH03 Overview

LS011B7DH03 is a 1.1 inch diagonal CG-Silicon display screen product, without backlight, without touch screen.LS011B7DH03 supports display 160×68 with aspect ratio of 21:9 (W:H), whose pixels are arranged in Rectangle.It features active area of 25.28(W)×10.744(H) mm, outline size of 32(W)×14(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 0.73g (Typ.). As a TN, Normally White, Reflective LCM product, LS011B7DH03 can provides , 20:1 (Typ.) reflective contrast ratio, 60/60/60/60 (Typ.)(CR≥2) (L/R/U/D) viewing angle , and response time of 10/20 (Typ.)(Tr/Td) ms., thus presenting a palette of Monochrome colors.

LS011B7DH03 Feature

-Reflective
-Matte
-Sunlight Readable

Screen Size:1.1 inch
Resolution:160x68
Brand:Sharp
LS011B7DH03 1.1 Inch 160x68 Sunlight Readable LCD Display.

LS011B7DH03 Application

For Wearable & Industrial LCD.

To operate in low-light conditions, RLCDs need to be paired with an efficient front light solution such as the Youritech Front Light Panel.With improved optical coupling, collimation, and attenuation, our front light solution efficiently delivers more light exactly where you need it, and efficient LEDs can be used without experiencing typical issues with diffusion and material losses. Plus, as few as one low-power LED can be used in a front light instead of the five or more LEDs needed for alternative display light guides, making our solution the most efficient front light option available today.

It means your devices can stop relying on power-hungry backlights. By reinventing light guide and front light technology, we makes it possible to fully embrace the inherent power-saving features of RLCDs – from the brightest outdoor to the darkest indoor lighting environments.
