LQ104V1DG74 Sharp 10.4 Inch TFT LCD Display 640x480 CMOS Wide Temperature LCD Module

LQ104V1DG74 Overview

LQ104V1DG74 is a 10.4 inch diagonal a-Si TFT-LCD display screen product from Sharp, with a built-in WLED backlight, With LED Driver, without touch screen.LQ104V1DG74 supports display 640(RGB)×480 (VGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 211.2(W)×158.4(H) mm, outline size of 227.3(W)×177.5(H)×10.5(D) mm, viewing area size of 215.4(W)×161.8(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 500g. As a TN, Normally White, Transmissive LCM product, LQ104V1DG74 can provides 370 cd/m² display brightness 800:1 transimissive contrast ratio, 80/80/60/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 35 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 70K hours, With LED Driver. LQ104V1DG74 utilizes CMOS (1 ch, 6-bit) as it's signal inputting systerm, which connected by 40 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.

LQ104V1DG74 Feature

-Wide Temperature
-WLED Backlight
-With WLED Driver
-Life≥70K hours
-Matte
-180 °C Reverse

Screen Size:10.4 inch
Resolution:640x480
Brand:Sharp
LQ104V1DG74 Sharp 10.4 Inch 640x480 CMOS Wide Temperature TFT LCD Display.

LQ104V1DG74 Service & Technology

LQ104V1DG74 Application
