LQ084S3LG11 Sharp 8.4 Inch TFT LCD Display 800x600 LVDS Wide Temperature LCD Module

Part No.:LQ084S3LG11
Size:8.4″ inch
Resolution:800x600
Panel Interface:LVDS (1 ch,6/8-bit)
Display mode:TN,Transmissive
Outline Dimension:200(W)x152(H)mm
Active Area:170.4(W)x127.8(H)mm
Viewing Angle L/R/U/D:80/80/80/80 (Typ.)
Brightness（cd/m2）:500cd/m²(Typ.)
Operation / Storage Temp:-30~80°C / -30~80°C
Touch:no

LQ084S3LG11 Overview

LQ084S3LG11 is a 8.4 inch diagonal a-Si TFT-LCD display screen product from Sharp, with a built-in WLED backlight, With LED Driver, without touch screen. LQ084S3LG11 supports display 800(RGB)×600 (SVGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 170.4(W)×127.8(H) mm, outline size of 200(W)×152(H)×9.8(D) mm, viewing area size of 173.4(W)×130.8(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 330g (Max.). As a TN, Normally White, Transmissive LCM product, LQ084S3LG11 can provides 500 cd/m² display brightness 600:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 35 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 8-bit gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 51% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, With LED Driver. LQ084S3LG11 utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
