LQ080Y5DR01 Overview
LQ080Y5DR01 supports display 800(RGB)×480 (WVGA) with aspect ratio of 15:9 (W:H), whose pixels are arranged in RGB Vertical Stripe.It features active area of 174(W)×104.4(H) mm, outline size of 190(W)×120(H)×19.2(D) mm, with surface treament of Antiglare, Antireflection, net weight of 392g (Typ.). As a TN, Normally White, Transmissive LCM product, LQ080Y5DR01 can provides 625 cd/m² display brightness 100:1 transimissive contrast ratio, 65/65/55/65 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 30/50 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted 2 pcs CCFL as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, external backlight driver is additionally needed. LQ080Y5DR01 utilizes Parallel RGB (1 ch, 6-bit) as it's signal inputting systerm, which connected by 40 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
Application
For Industrial.
