LQ080Y3LW01A Sharp 8 Inch TFT LCD Display 800x480 LVDS High Brightness Wide Temperature LCD Module

Part No.:LQ080Y3LW01A
Size:8″ inch
Resolution:800x480
Panel Interface:LVDS (1 ch,8-bit)
Display mode:ASV,Normally Black,Transmissive
Outline Dimension:191.8(H)x120.7(V)mm
Active Area:174(H)x104.4(V)mm
Viewing Angle L/R/U/D:80/80/80/80 (Typ.)
Brightness（cd/m2）:650(Typ.)
Operation / Storage Temp:-30~85°C / -40~90°C
Touch:no

LQ080Y3LW01A Overview

LQ080Y3LW01A is a 8.0 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, without touch screen.LQ080Y3LW01A supports display 800(RGB)×480 (WVGA) with aspect ratio of 15:9 (W:H), whose pixels are arranged in RGB Vertical Stripe.It features active area of 174(W)×104.4(H) mm, outline size of 191.8(W)×120.7(H) mm, viewing area size of 177.4(W)×107.8(H) mm, with surface treament of Antiglare, net weight of 280g (Max.). As a ASV, Normally Black, Transmissive LCM product, LQ080Y3LW01A can provides 650 cd/m² display brightness 1800:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 40 (Max.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors. This product adopted 6S3P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 10K hours, external backlight driver is additionally needed. LQ080Y3LW01A utilizes LVDS (1 ch, 8-bit) as it's signal inputting systerm, which connected by 32 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
