LPM012A154A JDI 1.2 Inch Round TFT LCD Display 218x218 Reflective Circular LCD For Wearable

LPM012A154A Overview
LPM012A154A supports display 218(RGB)×218 with aspect ratio of 1:1 (W:H), whose pixels are arranged in RGB Vertical Stripe.It features active area of 30.411(W)×30.411(H) mm, outline size of 33.811(W)×35.611(H)×1.156(D) mm, viewing area size of 31.411(W)×31.411(H) mm, with surface treament of Hard coating (2H), net weight of 2.10g. As a ECB, Normally Black, Reflective LCM product, LPM012A154A can provides , 20:1 (Typ.) reflective contrast ratio, 60/65/65/60 (Typ.)(CR≥2) (L/R/U/D) viewing angle , and response time of 3/6 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 2-bit gray scale signal for each dot, thus presenting a palette of 64 colors, also with performance of color gamut 23% (NTSC).

Screen Size:1.2 inch
Resolution:218x218
Brand: JDI
1.2 Inch 218x218 Reflective Round LCD Display
Refresh Rate:30Hz

Application
For Wearable.
