LQ043Y1LX01 Overview
LQ043Y1LX01 supports display 480(RGB)×800 (WVGA) with aspect ratio of 3:5 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 56.16(W)×93.6(H) mm, outline size of 64.66(W)×108.48(H) mm, net weight of 61.0g (Typ.). As a ASV, Normally Black, Transmissive LCM product, LQ043Y1LX01 can provides 315 cd/m² display brightness, best view direction on Symmetry . Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type. LQ043Y1LX01 utilizes LVDS (1 ch, 8-bit) as it's signal inputting systerm. It's typical vertical frame rate (Fv) is 60Hz.
Application
For Industrial.
