HSD156JUW2-A12 HannStar 15.6 Inch TFT LCD Display 1920x1080 High Brightness Wide Temperature LCD Module

HSD156JUW2-A12 Overview
HSD156JUW2-A12 is a 15.6 inch diagonal a-Si TFT-LCD display screen product from HannStar, with a built-in WLED backlight, without backlight driver, without touch screen.HSD156JUW2-A12 supports display 1920(RGB)×1080 (FHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 344.16(W)×193.59(H) mm, outline size of 363.7(W)×215.7(H) mm, with surface treament of Hard coating, net weight of TBD. As a IPS Pro, Normally Black, Transmissive LCM product, HSD156JUW2-A12 can provides 850 cd/m² display brightness 1000:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 15/15 (Max.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 70% (NTSC).

Feature
IPS
Wide Temperature
3G Vibration
Hight Brightness 850cd/m2

Application
For Outdoor high brightness,Automotive display.
