| Product size | 7.0-inch | Type | LCM, LTPS TFT-LCD |
| Pixel Format | 1200(RGB)×1920 (WUXGA) 322PPI | Configuration | RGB Vertical Stripe |
| Active Area | 94.5 × 151.2 (H×V) | Outline Dim. | 98.7 × 160.8 × 3.67 (H×V×D) |
| Luminance | 450 cd/m² (Typ.) | Contrast Ratio | 1100 : 1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | - |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC | Light Source | 5S4P WLED , With LED Driver |
| Weight | 66.0g (Typ.) | Designed For | Pad & Tablet |
| Frequency | 60Hz | Touch Panel | Without |
| Interface Type |
MIPI (4 data lanes) , 31 pins Connector |
||
| Power Supply | 1.8/3.0/3.0V (Typ.)(IOVCC/VDD/VDDP) | ||
| Environment |
Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
||
