Factory supply 15 inch tft ips lcd panel 1920x1080 landscape lcd module high contrast eDP interface display for Pad Tablet

  • Part No.:NV150FHB-T30
  • Size:15″ inch
  • Resolution:1920x1080
  • Panel Interface:eDP (2 Lanes)
  • Display mode:ADS,Transmissive
  • Outline Dimension:343.24(W)x197.21(H)mm
  • Active Area:332.064(W)x186.786(H)mm
  • Viewing Angle L/R/U/D:85/85/85/85 (Typ.)
  • Brightness（cd/m2）:0cd/m²
  • Operation / Storage Temp:0~50°C / -20~60°C
  • Touch:no
Get a quote

Product Description

Product size
15.0-inch
Type
CELL , a-Si TFT-LCD
Pixel Format
1920(RGB)×1080 (FHD) 146PPI
Configuration
RGB Vertical Stripe
Active Area
332.064 × 186.796 (H×V)
Outline Dim.
343.24 × 227.67 × 1.82 (H×V×D)
Bezel Area
-
Treatment
Anti-Scatter
Luminance
0 cd/m²
Contrast Ratio
1000 : 1 (Typ.) (TM)
View Direction
Symmetry
Response Time
30 (Typ.)(Tr+Td) ms
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Operating Mode
ADS, Normally Black, Transmissive
Support Color
16.7M 100% sRGB
Light Source
No B/L
Glass Thickness
0.40+0.40 mm
Transmissivity
5.6% (Typ.)
Weight
-
Designed For
Laptop
Frequency
60Hz
Touch Panel
On-Cell Touch
Interface Type
eDP (2 Lanes) , 40 pins Connector
Power Supply
3.3V (Typ.)
Environment
