Factory 4 inch AM-OLED lcd screen display 360x640 oled screen MIPI for industrial products

Part No.:AMS395GB02
Size:4″ inch
Resolution:360x640
Panel Interface:MIPI (1 data lane)
Display mode:/
Outline Dimension:53.76(W)x97.16(H)mm
Active Area:49.14(W)x87.36(H)mm
Viewing Angle L/R/U/D:/
Brightness（cd/m2）:300cd/m²(Typ.)
Operation / Storage Temp:-15~70°C / -40~85°C
Touch:no

Product Description

Product size	4.0-inch	Type	OLED , AM-OLED
Pixel Format	360(RGB)×640 (nHD) 186PPI	Configuration	RGB Vertical Stripe
Active Area	49.14 × 87.36 (H×V)	Outline Dim.	53.76 × 97.16 (H×V×D)
Luminance	300 cd/m² (Typ.)	Contrast Ratio	1300 : 1 (Typ.) (TM)
View Direction	-	Response Time	-
Viewing Angle	-	Operating Mode	-
Support Color	16.7M 105% NTSC	Light Source	self
Weight	22.9g (Typ.)	Designed For	Mobile Phone
Frequency	60Hz	Touch Panel	Without
Interface Type	MIPI (1 data lane) , 20 pins Connector
Power Supply	3.7/1.8V (Typ.)(VPNL/VDDI)
Environment	Storage Temp.: -40 ~ 85 °C Operating Temp.: -15 ~ 70 °C
