| LCD SPECIFICATION | |||
| Panel Size | 13.3 inch | Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080 , FHD | Pixel Format | RGB Vertical Stripe |
| Display Area | 293.76(W)×165.24(H) mm | Bezel Opening | - |
| Outline Size | 300.26(W)×177.55(H) ×4.4(D) mm | Surface | Antiglare, Hard coating (3H) |
| Brightness | 300 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Best View on | Symmetry | Response Time | 14/11 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | AAS, Normally Black, Transmissive |
| Display Colors | 262K 100% sRGB | Lamp Type | WLED , 15K hours , With LED Driver |
| Shape Style | Slim (PCBA Bent, T≤3.0mm) | Application | Laptop |
| Frequency | 60Hz | Touch Screen | Without |
| Signal Interface | eDP (2 Lanes) , 30 pins Connector | ||
| Input Voltage | 3.3V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C | ||
