Custom Factory 5.7 inch 640*480 TTL sunlight readable lcd display

Part No.:COM57H5M86KLC
Size:5.7″ inch
Resolution:640x480
Panel Interface:Parallel RGB (1 ch,6-bit)
Display mode:TN,Transflective
Outline Dimension:130.32(H)x101.2(V)
Active Area:115.2(H)x86.4(V)
Viewing Angle L/R/U/D:80/80/60/55 (Typ.)
Brightness（cd/m2）:550(Typ.)
Operation / Storage Temp:-20~70°C / -30~80°C
Touch:no

Product Description

Panel Brand	Ortustech	Panel Model	COM57H5M85KSC
Panel Size	5.7 inch	Panel Type	a-Si TFT-LCD , LCM
Resolution	640(RGB)×480 [VGA]	Pixel Configuration	RGB Vertical Stripe
Display Area	115.2×86.4 mm	Luminance	550 cd/m² (Typ.)
Treatment	Hard coating (3H)	Operating Mode	TN, Normally White, Transflective
Viewing Angle	80/80/60/55 (Typ.)(CR≥10)	Contrast Ratio	600:1 (Typ.) (TM)
Interface Type	TTL	Support Color	262K (6-bit)
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
