COM31H3P76ULC Ortustech 3.1 Inch Round LCD Sunlight Readable 480x480 Transflective Circular Display

COM31H3P76ULC Overview
COM31H3P76ULC is a 3.1 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, without touch screen.COM31H3P76ULC supports display 480(RGB)×480 with aspect ratio of 1:1 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 78.62(W)×78.62(H) mm, outline size of 88.83(W)×91.43(H) mm, with surface treament of Hard coating, net weight of 50.0g (Typ.). As a VA, Normally Black, Transflective LCM product, COM31H3P76ULC can provides 600 cd/m² display brightness 700:1 transimissive contrast ratio, 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 50 (Max.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 50% (NTSC).

Screen Size:3.1 inch
Resolution:480x480
Brand: Ortustech
3.1 Inch Sunlight Readable 480x480 Transflective Round OLED Display.
Refresh Rate:60Hz

Application
For Wearable.
