0.48"-5" LCD Display (2.5")

COM25T2855G Ortustech 2.5 Inch TFT LCD Display 479×240 Serial RGB LCD Screen

Part No.:COM25T2855G
Size:2.5″ inch
Resolution:479x240
Panel Interface:Serial RGB (8-bit) + SPI
Display mode:Transmissive
Outline Dimension:59.82x44.07mm(HxV)
Active Area:49.87x37.44mm(HxV)
Viewing Angle L/R/U/D:/
Brightness（cd/m2）:250cd/m²(Typ.)
Operation / Storage Temp:-10~70°C / -20~80°C
Touch:no

Overview
COM25T2855G supports display 479×240 with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Delta. It features active area of 49.87(W)×37.44(H) mm, outline size of 59.82(W)×44.07(H) mm, net weight of TBD. As a TN, Normally White, Transmissive LCM product, COM25T2855G can provides 250 cd/m² display brightness, best view direction on 6 o'clock , and response time of TBD ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors.

Application
For andheld & PDA,Industrial.
