| LCD SPECIFICATION | |||
| Panel Size | 7.0 inch
|
Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×768 [XGA] | Pixel Format | RGB Vertical Stripe |
| Display Area | 141.312(H)×105.984(V) mm | Bezel Opening | 164(H)×119.2(V) ×3.5(D) mm |
| Outline Size | 143.312(H)×107.984(V) mm | Surface | Antiglare, Hard coating (3H) |
| Brightness | 330 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Best View on | Symmetry | Response Time | 15/10 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Display Mode | MVA, Normally Black, Transmissive |
| Display Colors | 16.2M 54% NTSC | Lamp Type | WLED [3S9P] , 15K hours , W/O Driver |
| Weight | 139g (Typ.) | Application | Pad & Tablet |
| Frequency | 60Hz | Touch Screen | Without |
| Signal Interface | LVDS (1 ch, 8-bit) , 40 pins FPC | ||
| Input Voltage | 3.3/5.3/-5.3/15/-12V (Typ.)(VDDIO/VDPA/VDNA/VGH/VGL) | ||
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C | ||
