0.48"-5" LCD Display (4.5")

4.5 inch LCD 480x854 resolution RGB Interface with touch panel with back light for portable navigation application

Part No.:ET045FW01-KT
Size:4.5″ inch
Resolution:480x854
Panel Interface:
Display mode:TN
Outline Dimension:61.54x110.09x4.0
Active Area:55.44(Ｈ)x98.64(Ｖ)
Viewing Angle L/R/U/D:70 60 70 70
Brightness（cd/m2）:276
Operation / Storage Temp:-20～+70℃ / -30～+80℃
Touch:no

Banner1-2

Feature		Spec
Display Spec.	Size	4.5 inch
	Resolution	480*854
	Technology Type	module
	Pixel Configuration	RGB Vertical Stripe
	Viewing Direction	70 60 70 70
Mechanical Characteristics	LCM (W x H x D) (mm)	61.54110.094.0
	Active Area(mm)	55.44(H)*98.64(V)
	With /Without TSP	With TSP
	Driver IC	ILI9806E GT911
	Weight (g)	TBD
Electrical Characteristics	Interface	3SPI+16/18/24Bit RGB Interface
