0.48"-5" LCD Display (4.3")

4.3 IPS lcd screen wholesale 480x272 resolution OEM/ODM high brightness with full viewing angle for portable navigation

Part No.:ET043WQ03-K
Size:4.3″ inch
Resolution:480x272
Panel Interface:
Display mode:IPS
Outline Dimension:105.4x67.15x2.85
Active Area:95.04x53.86
Viewing Angle L/R/U/D:80 80 80 80
Brightness（cd/m2）:900cd/m2
Operation / Storage Temp:-30～+85℃ / -30～+85℃
Touch:no

4.3 IPS lcd screen wholesale 480*272 resolution OEM/ODM high brightness with full viewing angle for portable navigation

Feature		Spec
Display Spec.	Size	4.3 inch
	Resolution	480*272
	Technology Type	module
	Pixel Configuration	RGB Vertical Stripe
	Viewing Direction	80 80 80 80
Mechanical Characteristics	LCM (W x H x D) (mm)	105.467.152.85
	Active Area(mm)	95.04*53.86
	With /Without TSP	Without TSP
	Driver IC	SC7283
	Weight (g)	TBD
Electrical Characteristics	Interface	8/24 RGB

4.3 IPS lcd screen wholesale 480*272 resolution OEM/ODM high brightness with full viewing angle for portable navigation
