| Product size | 2.2-inch | Type | LTPS TFT-LCD, LCM |
| Pixel Format | 240(RGB)×320 [QVGA] 180PPI | Configuration | RGB Vertical Stripe |
| Active Area | 33.84(H)×45.12(V) mm | Outline Dim. | 40.6(H)×56.6(V) mm |
| Luminance | 195 cd/m² (Typ.) | Contrast Ratio | 150:1 (Typ.) (TM) 8:1 (Typ.) (RF) |
| View Direction | - | Response Time | 14 (Typ.)(Tr+Td) |
| Viewing Angle | 55/45/45/60 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transflective |
| Support Color | 65K 50% NTSC | Light Source | WLED [4S1P] |
| Weight | - | Designed For | Mobile Phone |
| Frequency | - | Touch Panel | Without |
| Interface Type | CPU , 39 pins FPC | ||
| Power Supply | 2.8V (Typ.)(DVDD) | ||
