100% original 4 inch 600x800 TFT lcd screen display panel module RGB for handheld device

  • Part No.:LS040S3DX01
  • Size:0″ inch
  • Resolution:600x800
  • Panel Interface:Parallel RGB (1 ch,8-bit)
  • Display mode:Transmissive
  • Outline Dimension:65.5(H)x90(V)
  • Active Area:60.75(H)x81(V)
  • Viewing Angle L/R/U/D:80/80/80/80 (Typ.)
  • Brightness（cd/m2）:380(Typ.)
  • Operation / Storage Temp:-20~60°C / -30~70°C
  • Touch:no
Get a quote

Product Description

Product size 4.0-inch Type LCM, LTPS TFT-LCD
Pixel Format 1200(RGB)×1920 (WUXGA) 322PPI Configuration RGB Vertical Stripe
Active Area 94.5 × 151.2 (H×V) Outline Dim. 98.7 × 160.8 × 3.67 (H×V×D)
Luminance 450 cd/m² (Typ.) Contrast Ratio 1100 : 1 (Typ.) (TM)
View Direction Symmetry Response Time -
Viewing Angle 80/80/80/80 (Min.)(CR≥10) Operating Mode IPS, Normally Black, Transmissive
Support Color 16.7M 72% NTSC Light Source 5S4P WLED , With LED Driver
Weight 66.0g (Typ.) Designed For Pad & Tablet
Frequency 60Hz Touch Panel Without
Interface Type MIPI (4 data lanes) , 31 pins Connector
Power Supply 1.8/3.0/3.0V (Typ.)(IOVCC/VDD/VDDP)
Environment Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C
